Ds1302 Real Time Clock Module(Without Battery)
Ds1302 Real Time Clock Module(Without Battery)
Keywords: Ds1302 Real Time Clock Module(Without Battery)
Part No.:PMS051
Description:
31 x 8 RAM for scratchpad data storage
Serial I/O interface for minimum pin count
Wide Working Voltage: 2.0 ~ 5.5V
Single-byte and multi-byte transmission for clock or RAM data read / write
TTL-compatible (Vcc=5V)
Working Temperature: 0 to +70 Deg C
32.768KHz crystal oscillator
This module is coming without button battery due to embargo law against battery from Airlines.
Wiring:
Vcc - +5V / 3.3V
GND - GND
CLK - P01
DAT - P02
RST - P00
31 x 8 RAM for scratchpad data storage
Serial I/O interface for minimum pin count
Wide Working Voltage: 2.0 ~ 5.5V
Single-byte and multi-byte transmission for clock or RAM data read / write
TTL-compatible (Vcc=5V)
Working Temperature: 0 to +70 Deg C
32.768KHz crystal oscillator
This module is coming without button battery due to embargo law against battery from Airlines.
Wiring:
Vcc - +5V / 3.3V
GND - GND
CLK - P01
DAT - P02
RST - P00
Specifications
| Dimensions (cm) | 4.5 x 2.3 x 1.1 |
|---|---|
| Weight (kg) | 0.006 |
